Product Parameter

Features

1,One second measurement, simple and convenient;

2,32 sets of memory data;

3,Large screen backlight display;

4,Safe and practical, long service life;

5,Three colors change, the fever will show red

6,Advanced probe, accurate measurement;

7,Temperature and body temperature measurement one-click conversion;

8,Celsius and Fahrenheit convertible with adjustable accuracy

Precautions

●Please read the instruction carefully before use.

●Do not immerse the thermometer in any liquid,and do not leave it under overheat

or low temperature environment for a long time.

●Collision prohibited. Dropping and mixing with sharp objects are prohibited.disassemble

by yourself is prohibited.

●The thermometer should not be used in the sun or water.

●Do not use in strong electromagnetic interference environment.

●Keep the thermometer out of the reach of children.

●It is recommended to practice several time to become familiar with the measuring method,

and try not to change the product factory settings.

●Measurement results are not a substitute for physician diagnosis.

●No special maintenance is required during use,please contact the seller or manufacturer

if there is any malfunction appears.

Operation Instrctions

1.Switch between body and object temperature mode

when in measurement mode,press the “SET”key to switch between the object temperature

measurement mode(the display shows a small house) and the human body temperature

measurement mode(the display shows the child's smiling face)

• Look up the measured historical data

In the shutdown state,press the “MEMO” key to view the last first measured data,and press

it again to view the last second data.The thermometer can store 32 sets of data measured

in the human body temperature measurement mode.Press the “POW”key to exit the look up.

• Set parameters of the themometer

• Turn sound on an off

In the shutdown state,press and hold the “SET”key to 3 seconds until the screen lights up.

In F1 mode,press “MEMO” to select on or off.Press “POW” to exit the setting.

• Set the temperature abnormal alarm threshold

In F1 mode,lightly press “SET” button to enter F2 mode,in this state,press “MEMO” button

to set the temperature.Press “POW” to exit the setting.

• Set temperature compensation

In F2 mode,lightly press “SET” button to enter F3 mode,

press press “MEMO” button to set the temperature compensation.This operation is more

professional,it is recommended to keep the factory default settings and set the value to zero.

Press “POW” to exit the setting.

• Switch between Celsius/Fahrenheit temperature units

In F3 mode,lightly press “SET” button to enter F4 mode,press

“MEMO” key to set the temperature unit(Celsius/Fahrenheit switching selection).

Certificates

FAQ

Q1:The device is on (the screen is measured),but the temperature cannot be measured.

A1:Confirm whether the product enters the measurement data viewing mode or parameter

setting mode.If you under this mode,please press the power button(POW key) to shut down

(or wait 1 minute to automatically shut down),and then press the temperature measurement

key after rebooting.

Q2:The temperature measurement is obviously too low

A2:Confirm whether the device is under the object temperature measurement mode.If so,press

the SET key once to enter the human body temperature measurement mode.Enter the parameter

setting mode and check whether the temperature compensation setting is negative.It is recommended

to set the value to 0.

Q3:The measurement temperature is obviously too high

A3:Enter the parameter setting mode and check whether the temperature compensation setting

is positive.It is recommended to set the value to 0.
