1-10cm Distance 30DB Body Ear Forehead Infrared Thermometer
Parameters
| Poduct Name | Newly Body Forehead Ear Temperature Sensor Infrared Fever
Thermometro Digital |
Brand Name | Care4U |
Model Numbe | ZLK-IRT101 |
Warranty | 1 year |
Material | Plastic ABS and electronic component |
Quality Certification | CE FDA ROHS ISO13485 |
Instrument classification | Class II |
| Power suplier | 2*1.5V AAA Batteries |
Power | Removable Battery |
Display | LCD Screen |
Measuring distance | 3-5cm(recommend distance) |
Sound | Buzzer, 30 DB , Switch control |
| Measuring range | Body:,89~109°F/32~42°C Object:32~212°F/0~100°C |
| Operating ambient temperature | 50~104°F/10~40°C |
| Operating ambient humidity | Less than or equal to 80%RH |
| Storage temperature range | -13~-131°F/-25~-55°C |
Packing
Unit Size:170*116*55mm
Net Weight:150g(without batteries)
Carton Size:605*360*295mm 50pcs/carton
Carton Weight:8.65kgs
Maintenance and Precautions
●Hold the device perpendicular to the forehead about 3-5 cm away
and instruct the
person to remain stationary during measurements.
●When the ambient temperature varies greatly around forehead,please
measure
the earlobe back instead.
Please keep the inner cavity of the sensor and probe
clean,otherwise it will
affect the measurement accuracy.
- Surface cleaning:wipe surface dirty with a clean soft cloth or
cotton swab with
- a little medical alcohol or water.
- Sensor and inner cavity cleaning:use a clean soft cloth or cotton
swab to stick
- a little medical alcohol gently wipe the inner cavity of the probe
or the top of
- the sensor,use until the alcohol is completely evaporated.
●Please read the instruction carefully before use.
●Do not immerse the thermometer in any liquid,and do not leave it
under overheat
or low temperature environment for a long time.
●Collision prohibited. Dropping and mixing with sharp objects are
prohibited.
disassemble by yourself is prohibited.
●The thermometer should not be used in the sun or water.
●Do not use in strong electromagnetic interference environment.
●Keep the thermometer out of the reach of children.
●It is recommended to practice several time to become familiar with
the measuring
method,and try not to change the product factory settings.
●Measurement results are not a substitute for physician diagnosis.
●No special maintenance is required during use,please contact the
seller or
manufacturer if there is any malfunction appears.
Features
1, HD LCD Screen
2, Non Contact Measuring
3, One Second Reading
4, Body and Surface Mode
5, 32 Record Storage
6, ℃/℉ Conversion
7, Fever Alarm
8, Voice On/Off
How to use it?
1.Switch between body and object temperature mode
when in measurement mode,press the “SET”key to switch between the
object
temperature measurement mode(the display shows a small house) and
the human
body temperature measurement mode(the display shows the child's
smiling face)
- Look up the measured historical data
In the shutdown state,press the “MEMO” key to view the last first
measured data,and
press it again to view the last second data.The thermometer can
store 32 sets of data
measured in the human body temperature measurement mode.Press the
“POW”key
to exit the look up.
- Set parameters of the themometer
In the shutdown state,press and hold the “SET”key to 3 seconds
until the screen
lights up.in F1 mode,press “MEMO” to select on or off.Press “POW”
to exit the setting.
- Set the temperature abnormal alarm threshold
In F1 mode,lightly press “SET” button to enter F2 mode,in this
state,press “MEMO”
button to set the temperature.Press “POW” to exit the setting.
- Set temperature compensation
In F2 mode,lightly press “SET” button to enter F3 mode,
press press “MEMO” button to set the temperature compensation.This
operation is
more professional,it is recommended to keep the factory default
settings and set the
value to zero.Press “POW” to exit the setting.
- Switch between Celsius/Fahrenheit temperature units
In F3 mode,lightly press “SET” button to enter F4 mode,press
“MEMO” key to set the temperature unit(Celsius/Fahrenheit switching
selection).
